Cutaway of an AvaMax fixed hybrid: PMMA teeth and base over the printed titanium core with screw-access connections

AvaMax Fixed Hybrids

Screw-retained. One piece with titanium.

A printed titanium core with high-pressure AvaDent XCL PMMA molded over and through it as one piece, so there’s no bond line to delaminate and no teeth to pop off.

Start your first case

Visits: 3 visits: scans, full-color try-in, delivery
Turnaround: Design preview in 1–2 business days; completed 10 business days after approval
Weight: Lightweight, and more affordable than ceramic restorations
Replacements: A digital record of every prosthesis, kept on file for replacements

AvaMax or solid bar

Every AvaDent hybrid is milled from the same monolithic XCL material: nearly monomer-free, pre-shrunk before milling, and resistant to bacteria and stains.

AvaMax titanium core
The framework is designed digitally after the prosthesis, then fully encased in PMMA for complete mechanical retention.
Wrap-around solid bar
The bar is fully encased in acrylic. The preferred solid bar design when there’s enough vertical space.
Montreal solid bar
The alternative when limited vertical dimension doesn’t allow the acrylic to wrap fully around the bar.

Specifications

All clinical workflows

Material: AvaDent XCL, a high-density, extreme cross-linked PMMA, molded under high pressure for a porosity-free prosthesis.
Core: Printed titanium, designed digitally after the prosthesis to support its function. The PMMA penetrates the core, so it can’t delaminate.
Retention: Screw-retained fixed full-arch prosthesis on implants, removable by the clinician for maintenance.
Occlusion: Occlusion and implant connections are milled together as the final step, for precise occlusal alignment.
Try-in: Full-color try-in with abutment-level connections, or a Hybrid Try-In that copies the final exactly.
Turnaround: Design preview in 1–2 business days; completed 10 business days after approval. Free 2-day FedEx.

Digital workflow · 3 visits

Records to send

360° scans of well-fitting dentures or try-ins, seated passively in the same interocclusal record
Soft-tissue scan with the healing abutments in place
Soft-tissue scan with the scan bodies in place

AvaMax Hybrid workflow

Physical records

Records to send

A verified final impression and soft-tissue master cast, plus an opposing cast
The screw-retained existing prosthesis (temporary converted denture) attached to the master cast
An interocclusal record between the existing prosthesis and the opposing arch

Hybrid Try-In

“The patients that come to my practice expect the best possible outcomes. Seeing the failures that happen from traditional fixed complete dentures, I switched to the AvaDent Monolithic process. I am able to make any changes I want to the design, enabling me to please the most demanding patient.”

Dr. Josh Renk

Backed by independent research

More than 15 published studies since 2015 compare AvaDent milled prostheses with conventional and 3D-printed alternatives on fit, strength, color stability and patient visits.

See the clinical studies

Questions clinicians ask

How long does a case take?

You’ll get a digital design preview within 1–2 business days of complete records. After you approve it, the hybrid is completed in 10 business days and ships free by 2-day FedEx.

How is AvaMax different from a conventional bar hybrid?

Conventional hybrids are made in two pieces, which risks fractures and staining. AvaMax is one piece: the titanium core and PMMA are integrated digitally, so they can’t separate.

Can I verify the design before the final?

Yes. The full-color try-in with abutment-level connections lets you check smile line, midline, occlusion, phonetics and lip support. A Hybrid Try-In is an exact monolithic copy of the final that you can adjust by grinding or adding material.

Who can answer a clinical question?

Email customerserviceus@avadent.com or call 480-275-7144, Monday to Friday, 8 AM to 5 PM MST.

Start your first hybrid case

New to AvaDent? Create an account and schedule onboarding with our support team.

Start your first case Already a customer? Send a case in the portal
